DC Shunt Generators
DC shunt generators have been the running horse for the industry since DC shunt generators have been the most used due to their very simple speed control, Ruggedness & high torque capabilities. This model is the industrial /education model suitable for the demonstration to students the complete known of the basics, components, starting methods, wear & tear & maintenance of these motors packages in small ratings.
Students can make connections of their own with the help of the terminations provided for study of features viz starting methods, speed control, speed torque, effect of field voltage, effects of Armature voltage, motors/generators operations.
Solid yoke list of experiments behavior of resistance cut off methods of starting behavior of voltage control methods of starting speed control & over speed operation load test & no load test of machine speed torque analysis voltage speed analysis efficiency analysis of commutation cold resistance & hot resistance motor operation parameters. Generator operation parameter basic overhauling.
